Portkeys LH5C 5.4″ Camera Control Monitor

The Portkeys LH5C 5.4″ Camera Control Monitor is a professional 5.4-inch on-camera monitor with 800nits of brightness, HDMI video input/output ports, Rec.709 color and 85% DCI-P3 coverage, 3D-LUT output capabilities, and wired camera control features. This monitor features a 5.4” LCD touchscreen with 800nits brightness, a 1,000:1 contrast ratio, and a large 178° viewing angle.

The display has a 1080p resolution (1920 x 1152), and it covers 100% of Rec.709 and 85% of DCI-P3 color spaces. The LH5C comes with a 10-bit (8+2 FRC) panel for high color fidelity and no color banding artifacts.

With dimensions of only 13.5 x 8.2 x 2.2cm/5.3 x 3.3 x 0.8in for a weight of 162g/5.7oz, the LH5C is a slim and lightweight monitor that will fill like a natural extension of your camera body.

Features

• 5.4-inch,10-bit (8+2 FRC) panel with a resolution of 1920 x 1152 and a 1000:1 contrast ratio.
• Maximum brightness of 800nits, 85% DCI-P3 coverage.
• 1 x 4K HDMI input, 1 x HDMI output.
• Professional monitoring tools: RGB and Luma Waveform, Anamorphic Image De-Squeeze, Peaking, ARRI False Color.
• 3D LUT monitoring and 3D LUT HDMI output capabilities.
• Built-in Sony NP-F style battery plate.
• USB-C 3.0 5V power input port.
• Low power draw: only 7.5W.
• Lightweight and rugged ABS + PC housing: only 162g/5.7oz.
