No Longer Available
This product is no longer available and is discontinued
Expected Delivery -
Order Now:
$197.70 / month
The HEDEN M26VE Motor is a quiet, yet high-torque lens motor for driving focus, zoom, or iris rings on cinema or ENG lenses. The included 0.8 MOD gear interfaces with standard cine lenses or photo lenses with gear rings and can be attached on either side of the motor. The high torque of the motor can drive most lenses, regardless of mechanical stiffness due to cold weather or age. Secure the motor itself to your rig using the 19mm rod clamp, which includes a 15mm bushing for lightweight setups. This particular model of M26VE features 256 encoders and a 3.3k resistor for compatibility with HEDEN and Bartech equipment. A 7-pin LEMO connection provides both power and control signals to the motor from the receiver or motor driver.
| Connector | 7-pin LEMO |
| Torque | 1.8 Nm |
| Dimensions | 1.3 x 1 x 4.6" / 3.3 x 2.6 x 11.7 cm |
| Weight | 7.8 oz / 222 g (motor only) |
| Packaging Info | |
|---|---|
| Package Weight | 0.65 lb |
| Box Dimensions (LxWxH) | 6.7 x 3.8 x 1.2" |
